Hydraulic Actuated Double Diaphragm Pumps


Microtech wide range of comprises of Hydraulic Actuated Diaphragm Pumps (MEMM-IIS1) which have been manufactured adopting superior quality raw material. These can be customized as per the specifications of our clients and have a long performing life.

Liquid Contact Materials (Wetted Parts)

  • PTFE Diaphragm
  • AISI 304
  • AISI 316
  • Monel
  • Alloy 20
  • Hast alloy B
  • Propylene
  • Hast alloy C
  • Titanium
  • GFT
  • PP
  • PTFE
  • PVC


Technical specifications and features of our pumps are

  • Double diaphragm with reputure indication also available
  • Can easily handle most of the liquids
  • Simplex and multiplex arrangements of pumps available for universal use
  • Heating or cooling jackets for liquid head available
  • Pressure (Kg./Sq. Cm.) Max 80
  • Mini max make HD type diaphragm gland less pumps
  • Leak free operation
  • Flow rates of 0To 800 LPH, & High discharge pressures of 180 Kg/sq. cm. can be achieved
  • Steady State metering accuracy of +/- 1% of pump output, at single setting of stroke from 10%-100%
  • Reproducibility (Repeatability) better than +/- 1.5% of set point
  • Inbuilt Pressure Relief & vacuum valve on the hydraulic side to safeguard system

Specifications

Type Hydraulic Diaphragm Pumps
Certification ISO 9001:2008 Certified, MSME
Application Acidic Material, Barrels, High Viscous Liquid, Slurry Transfer, Medical Equipments And X-ray Film Plantsa
Weight 100-150kg, 150-200kg, 200-250kg, 250-300kg, 50-100kg
Color Brown, Grey, Light White, White, ANY COLORS
Voltage 110V, 220V, 380V, 440V
Condition New
Power 1-3kw, 3-6kw, 6-9kw, 9-12kw, ANY
Driven Type Hydraulic
Pressure 0-10Bar, 10-20Bar, 20-40Bar, 40-80Bar
Warranty 1yr
Pipe size 0.5Inch, 1.5Inch, 1Inch, 2Inch, 3Inch, 4Inch, 5Inch, 6Inch
Automation Grade Manual, Semi Automatic
Flow Rating 0-500LPM, 1000-1500LPM, 500-1000LPM
Brand Name M/S MICROTECH ENGINEERING
Fuel DIESEL
Usage Bottling Plants, Beverages, Alkaline Solution, Water Treatment Plants, Cement Plants
Theory POSITIVE DISPLACEMENT PUMP
MOQ 01

Additional Information

Product Code HADDP
Min. Order Quantity 1 Piece(s)
Port ALL INDIA
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time READY STOCK
Packaging Details WOODEN BOX.
