PP Chemical Process Pumps

Link Copied

35,000.00 / Piece(s)

Edit

Business Type	Manufacturer, Exporter, Supplier
Type	Chemical Process Pump
Use	Chemical Supply
Weight	100-150kg, 150-200kg, 200-250kg, 250-300kg, 50-100kg
Click to view more

Product Details

Color

Brown, Grey, Light White, White

Voltage

110V, 220V, 380V, 440V

Condition

New

Automatic Grade

Manual, Semi Automatic

Power

1-3kw, 3-6kw, 6-9kw, 9-12kw

Warranty

1year

pump power

10Hp, 2Hp, 3Hp, 5Hp, 7Hp

Pump RPM

1400, 2800

Brand Name

M/S MICROTECH ENGINEERING

Application

Dairy industries,Food processing plant,Pharmaceutical industries,Sugar & confectionery

Fuel

DIESEL

Theory

POSITIVE DISPLACEMENT PUMP

Pressure

1-3 KW 3-6 KW

Structure

Name

SS CHEMICAL PUMPS

Item Code

PCP

Pay Mode Terms

L/C (Letter of Credit),T/T (Bank Transfer),D/P,D/A,Other

Production Capacity

150

Delivery Time

READY STOCK

Packaging Details

WOODEN BOX.

Product Code

CCP

Port

ALL INDIA

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

We have invested a large amount for developing all-the-in-house storage facility that is managed and maintained by our diligent professionals. Also, it keeps us free from stock-out situations. Having captured all markets of Delhi(India), our company has emerged as an acknowledged provider of this product range.

Standard features :

Centrifugal single stage
Flange as per din standard back pull out design
Open / close impeller
Shaft sealing by single / doable mechanical seals grease lubricated, deep grove ball bearing
The pump handle liquid having viscosities up to 1500 centrioles also with flame proof motor

Optional features :

Shaft sealing by gland packing
Bearing lubricating by oil
ANSI drilling on DIN flanges
Trolley mounting arrangement
Various type of connection
Head - 49-meter
Capacity - 113-m³/h
Delivery-size - 12to100-mm
Temperature - (-10 to 95 degree Celsius test pressure - 7 kg/cm²)

Material :

Casing - PP, GFPP, PVDF
Shaft - st. steel ( SS 410 / SS 316 / SS 304 )
Impeller - PP, GFPP, PVDF

Reliability : The pump are hydraulically designed for maximum efficiency. Every pump passes through stringent process & quality control plans and is designed to give longer life with consistent performance and trouble free service.

Application
